2x4 ft LED Troffer - Wattage & CCT Selectable (dip switch) - Watt: 50W-60W-72W - CCT: 4000K-5000K-6500K - 0-10V Dimmable

2x4 ft LED Troffer - Wattage & CCT Selectable (dip switch) - Watt: 50W-60W-72W - CCT: 4000K-5000K-6500K - 0-10V Dimmable

MPN: TR013
Quantity must be 1 or more
Regular Price:
Regular price
CAD 389.99

  • 30 Days Return
  • 5 Years Warranty
Sold only by the Case of 1.

2x4 ft LED Troffer - Wattage & CCT Selectable (dip switch) - Watt: 50W-60W-72W - CCT: 4000K-5000K-6500K - 0-10V Dimmable
Regular price
CAD 389.99
Sale price
CAD 389.99

2x4 LED Troffer Center Basket Panel for Drop Ceiling, CCT Watt Tunable LED Flat Troffer, Ideal for Homes Offices Hotels Hospitals

The 2x4 ft LED troffer is a versatile lighting solution that allows complete customization of both wattage and color temperature through a simple dip switch. With wattage options ranging from 50W to 72W and color temperature options including 4000K, 5000K, and 6500K, you can adjust the lighting to suit your specific needs. In addition to the customizable options, this troffer offers 0-10V dimming capabilities, making it easy to adjust the light levels to create the perfect ambiance for any space. The long-lasting LED technology is energy-efficient and reduces maintenance costs, making it an ideal choice for both commercial and residential settings. The high-quality construction and efficient performance make it an excellent long-term investment for any business or homeowner looking to upgrade their lighting.

Beam Angle

Featureof 2X4 Troffer.

  • Dimensions: L 47.7"x W 23.7" x H1.95"
  • Wattage adjustable option by dip switch
  • CCT adjustable option by dip switch
  • Transparent optics, controlled up light and down light distributions
  • CRI: >80 CRI
  • LED Lifetime: >50,000 Life Hours
  • Dimming: 0-10V
  • Materials: Aluminum
  • Mounting: Recessed
  • UL, DLC Listed
  • 5 years limited warranty

Easy Installation

The installation comes easy with the fixture being installed into the ceiling frame without any suspension. Follow manufacturer’s instructions for more details.

CRI >80

This T-Bar light has a rated color rendering index of less than 80. This means that the colors rendered by these lights are 80% accurate in comparison with an ideal light source.

150 Degree Beam Angle

A beam angle of 150 degree is what you get, when you choose troffer lighting fixture.

Premium LED Chips

We ensure highest quality of our products by having premium LED chips from Epistar. The chip is so embedded inside our LED troffer lighting fixture in such a way that highest operational efficiency is ensured.

Rugged Construction

The troffer is housed in rugged die-cast metal to ensure durability against any external stress or strain.

Thermal Heat Dissipation

LED troffer light has an excellent thermal management ability and hence can dissipate heat effectively, whatever heat that may be produced by the fixture.

UV and Mercury Free

LED troffer does not contain any harmful radiation such as ultraviolet rays in its light beam, nor does it have any toxic chemicals such as mercury or lead to cause any human or environmental hazard.

Low Cost Maintenance

Because of the technology that an LED troffer light utilizes to provide lighting, the product requires no or low maintenance for as long as it lasts, the total lifespan being 50,000 hours.


0-10 Dimmable

The LED troffer light comes with 0-10V dimmable option and is compatible with most standard dimmers in the market. When the dimmer brings down the light level to a minimum, it’s at 0 volts, while the peak light level is achieved at 10 volts.


No Dark Spot

The ultra wide beam angle the troffer has, it eliminates all the dark spots visible in any area.

Green, Eco-Friendly & Mercury-Free

Taking care of the environment is a responsibility that everyone should feel accountable for. The good thing is that lights and luminaries available at LEDMyPlace comply with environmental safety and can be categorized as Green Lights. These lights are completely free from toxic and hazardous chemicals like Mercury and Lead.

Rebate Eligible

Having the Energy Star approval, this product comes within the scope of rebate-eligibility norms.


Beam Angle: >110° Beam Angle
CCT: 5000 Kelvin
Color Rendering Index(CRI): >80 CRI
Dimensions (L x W x H): 47.7Lx23.7Wx1.95H
DLC Listed: Yes
IP Rating: IP20 Rated
Life Hours: >50,000 Hours
Lumens: 9000 Lumens
Operating Temprature: -4 Degree F To +113 Degree F
SKU: WEN-TRO261272-DN-T65-A-1PK/WEN-TRO261272-DN-T65-A-2PK
Warranty: 5 Years
Weight: 6.25 Lbs
Brand: LEDMyplace
Certifications: UL, DLC Listed
Color Temperature (Kelvin): 4000/5000/6500 Kelvin( CCT Changeable)
Dimmable: 0-10 Dimmable
Housing: Steel
Light Distribution: 125 Lm/W
MPN (Part No.): TR013
Replaces: 175 Watt Replacement
Voltage: 120-277 Volt
Wattage: 50w/60w/72W(selectable)
