T8 8ft LED Tube/Bulb - 48W 6720 Lumens 6500K Clear, Single Pin, Double End Power - Ballast Bypass Fluorescent Replacement, Commercial Grade
8ft LED Tube Light - 48W - Replace Fluorescent Tube of 170 Watts - 6500K -T8 Clear - 6720 Lumens - FA8 Base Double Ended Power
Our Double-Ended Power 8ft LED tube of 48W is available at 6500K color temperature. This LED Tube having a CRI of >80 and it can deliver lumens up to 6720. This Clear tube is an excellent substitute for T8, T10 & T12 fluorescent tubes. Our LED Tube can safely and easily replace a fluorescent tube of 170W and bring an energy-savings of 122W. Thus, a lower utility bill for you every month. Because this 48W LED tube is Double-ended-power, it will work without a ballast. Hence the existing ballast must be bypassed and directly wired to the line source for the tube fixture to work. These 48W LED tubes are housed by rugged die-cast aluminum for efficient heat dissipation. To emit illumination from the high standard ceiling, these LED tubes having a beam angle of 120 degrees, releasing enough bright light. This light has a long lifespan and has a shatterproof coating. LED Tubes from LEDMyplace is ETL listed and these listings make you eligible for a handsome rebate along with 5 years of warranty.
Features of T8 8ft LED Tube Light 48W 6720 Lumens, Single Pin:
- Available Wattage: 48 Watt
- Color Temperature Available: 6500K
- Luminous Efficacy: 130-140 Lm/W
- Wattage Equivalent: 170W
- Lifespan: 50,000 hours
- Voltage: 100V - 277V
- Beam Angle: 120 Degrees
- Cover : Clear
- Ballast Bypass [Works without a ballast]
- cETL, approved
- Warranty: 5 years
These LED tube light fixtures work without ballast(or bypassed ballast). Understand the step-by-step procedure of removing or bypassing a ballast by reading our guide.
Whether it’s a 2ft, 4ft or 8ft LED tube, one of the jaw-dropping features of LED tubes is that they don’t flicker unlike what you would have definitely observed in the case of fluorescent tubes. The LED tubes start instantly and once they start, they don’t flicker and produce a humming sound.
The LED tubes that are either clear or frosted have an IP22 rating. This rating signifies that our LED tubes are protected against dust-tight (objects in the dust that are of a size more than 1mm) and protected against water-ingress from all directions. For such reasons, LED tubes are safe for use in areas where there are moisture and water. E.g. Bathrooms, kitchens, etc.
The LED tubes accept an input voltage of 100V-277V. You can go for a waterproof transformer in case you don’t have this voltage and wish to convert this voltage range to some other.
Low Maintenance Cost
The LED tubes will require low or no maintenance if you are going for a ballast bypass option of LED tube installation. Though not very frequent, you may have to replace the ballasts once in the total lifetime of LED tubes, if you are going for the ballast compatibility option and hence you will have to bear with slightly higher maintenance costs when choosing the former option.
>50,000 Life Hours
The lifespan of LED tubes is no less than 50,000 hours or 5 years if the tubes are operated upon for 24 hours a day. Can last longer, if the tubes are kept ON for only 12 hours a day.
The CRI is greater than 80 for LED tubes, whatever object comes in the light distribution range appears to be real and natural up to 80% extent on a CRI scale of 1-100 and as it would have appeared in the natural light.
120 Degree Beam Angle
The 120 degrees or ultra-wide beam angle is made use of when large areas need to be covered. All our LED tubes whether clear or frosted have a 120-degree beam angle.
The LED tubes can save energy up to 75% in extreme contrast with fluorescent tubes that consume a lot of energy to bring you a higher energy bill. We highly recommend going for our LED tubes that are an excellent combo of lumen brightness and energy-savings.
Aluminium Heat Sink
The LED tubes have a big heat sink made of aluminum and that’s a pretty good reason as to why the LED tubes don’t warm up too soon to be inconsistent operation. This is in extreme contrast with the fluorescent tubes that warmed up too soon and required cooling down to operate efficiently.
Embedded inside the LED tube is a high-quality standalone chip -- SMD LED -- made from many numbers chips to ensure high performance and reliability.
|Base Type:||FA8 , Single Pin|
|Color Rendering Index(CRI):||>80 CRI|
|Dimensions (L x W x H):||93.81 x 1.15 x 1.32|
|IP Rating:||IP22 Rated|
|Light Distribution:||130-140 Lm/W|
|MPN (Part No.):||TB030|
|Beam Angle:||120 Degree Beam Angle|
|Color Temperature (Kelvin):||6500 Kelvin|
|Housing:||Aluminum + PC|
|Life Hours:||50,000 Hours|
|Operating Temprature:||-68 To +122 °F|
|Replaces:||170 Watt Replacement|
Questions & AnswersAsk a Question
It says is the description: "You simply need to bypass/ remove the fluorescent ballast...". What type of electrical work is needed? Are parts needed to replace the ends where the ballast plug in? My current type is a "push in" type, not a "twist" type... Sorry, I have no idea what model type this is. Thanks!
Not much work is needed. Basically, the ballast in your current fixture needs to be cut out. Then, these get wired as Hot on one end, Neutral on the other end, with a Single-Pin compatible tombstone at each end.
